Turbo Turbocharger AR.75 TH 0.83A/R Vband HFL-G35-1050 Ball Bearing New Design
Turbo Turbocharger AR.75 TH 0.83A/R Vband HFL-G35-1050 Ball Bearing New Design
Turbo Turbocharger AR.75 TH 0.83A/R Vband HFL-G35-1050 Ball Bearing New Design
This New Design High Flow Curved wheel Ceramic Dual Ball Bearing Point Milled Wheel Turbo.
Compressor Housing
a/r 0.75 anti-surge
air inlet 4″ air outlet 2.5″
inducer 68.07mm exducer 84.44mm
Compressor Trim: 65
Turbine Housing
a/r .83
Turbine Housing Inlet: 3 Inch O.D. V-Band
Turbine Housing Outlet: 3.55 inch (90mm)O.D. w/81mm centering ring V-Band
inducer 68.00mm exducer 62.30mm
Turbine Trim: 84
