Set of CV Axles for Can-Am Maverick X3 705401686, 705401687, 705502154
Set of CV Axles for Can-Am Maverick X3 705401686, 705401687, 705502154
Set of CV Axles for Can-Am Maverick X3 705401686, 705401687, 705502154
This is a set of Front & Rear CV axles for a Can-Am Maverick X3.They fit the following 64″ models:2017-2018 … Maverick X3/X3 Turbo STD & XDS-DPS2017-2018 … Maverick X3 Max/X3 Max Turbo STD & XDS-DPS2018 … Maverick X3 900 HO2019 … Maverick X3 Turbo/Turbo R STD2019 … Maverick X3 Max Turbo R*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly hardened steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
Inboard CV joint spline count: Fronts: 21, Rears: 30
Outboard CV joint spline count: Fronts: 29, Rears: 29
Compressed Length: FL 778, FR 735, RL 741, RR 741
Replaces Can-Am OEM # 705401686, 705402097, 705401687, 705402098, 705502154. Please note these are for 64″ models and do not fit 72″ XRS models
