Pair of Rear Axles for Polaris Ranger 500 700 800, 2204857 2204858
Product categories
- ATV Parts (5254)
- Bicycle Parts (5)
- Car Parts (9810)
- Go Kart Parts (40)
- Golf Cart Parts (1678)
- Lawn Mower Parts (2037)
- Minibike Parts (5)
- Motorboat Parts (200)
- Motorcycle Parts (2975)
- Other Parts (367)
- Scooter Parts (657)
- Simple Types (2)
- Snowmobile Parts (225)
- Tractor Parts (2378)
- Uncategorized (1)
- UTV Parts (2992)
- Variable Type (1)
Product tags
This is a pair of new, fully-assembled CV axles for a Polaris UTV.
pair of
They fit REAR, LEFT & RIGHT on the following models:
2007-2009 Ranger 500 2×4/4×4 (built after Aug 28 2006)
2007-2009 4×4 Ranger 700, Crew 700 (built after Aug 28 2006)
2007-2009 4×4 Ranger XP 700/XP 700 LE (built after Aug 28 2006)
2010-2017 6×6 Ranger 800
*Axles made as an OE replacement, and not intended for lifted/ modified vehicles
Product features:
Stronger than OEM chromoly forged steel axle bars
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
Inboard CV joint spline count: Left – 27/29, Right – 27
Outboard CV joint spline count: Left – 26, Right – 26
Compressed overall axle length: Left – 705 mm, Right – 660 mm
Replaces OEM # 2204858, 1332503, 1332576, 1332648, 1332722, 1332877, 2203742.
