Technical data of the carburettor: – Standard carburettor for separate lubrication – Electronic choke with 2-pin connection (500 mm) – Passage: 12 mm – Inlet connection: 16 mm inside with sealing ring, screwed hole distance 35 mm – Air filter connection: 28 mm outside – Fuel supply: for 5 mm hose – Float chamber ventilation – Adjustment options via mixture and idle speed screw Technical data of the air filter housing: – Dimensions: approx. 166x165x130 (mm) – Inner diameter of connections: 20 mm or 30 mm – Ready for installation with sealing ring – Black
